Rated Torque of 30,000 ft-lb for Everyday Use.
Wrist-Saver Door Latch Design
Rated Operating Pressure of 2,500 psi
Overnight Delivery Available for Parts
Quality, Serviceable Components
JAWS AVAILABLE: 2 3/8” – 6 1/4”
(Other sizes available upon request.)
OPTIONAL BACKUP JAWS: 2 3/8″ – 7″
Size range:
2-3/8″ to 6-1/4″
Rated Pressure:
2,500 psi
Rated torque:
30,000 ft-lb. (40,675nm)
Torque handle length:
32.5″ (82.55 cm)
Overall length (Doors Closed):
55.6″ (141.22 cm)
Overall width:
29.5″ (74.9 cm)
Overall height:
47.6″ (120.9 cm)
Size range:
2-3/8″ to 7″
Rated Pressure:
2,500 psi
Torque handle length:
32.5″ (82.55 cm)
Overall length (Doors Closed):
55.9″ (142 cm)
Overall width:
33.5″ (85.09 cm)
Overall height:
77.9″ (197.87 cm)
JAWS AVAILABLE: 2 3/8” – 6-1/4”
(Other sizes available upon request.)
Lift cylinder or spring hanger
Load cell/Torque gauge
w/o backup: 1,675 lbs (760 kg)
with backup: 2,900 lbs (1315.4 kg)
.
