Rated Torque of 40,000 or 60,000 ft-lb for Everyday Use.
Wrist-Saver Door Latch Design
Rated Operating Pressure of 2,500 psi
Overnight Delivery Available for Parts
Quality, Serviceable Components
JAWS AVAILABLE: 3-1/2” – 9-7/8”
(Other sizes available upon request.)
OPTIONAL BACKUP JAWS: 3-1/2″ – 10-3/4″
Part No:
40K: 79.45.03.33.01
60K: 79.60.06.33.01
Size range:
3-1/2″ to 9-7/8″
Rated Pressure:
3,000 psi; 2,250 psi; 2,000 psi
Rated torque:
40,000 – 60,000 ft-lb. (54,232 – 81,349nm)
Torque handle length:
36″ (91.4 cm)
Overall length (Doors Closed):
61.3″ (155.7 cm)
Overall width:
37″ (94 cm)
Overall height:
47.5″ (120.6 cm)
10-3/4″ BACKUP ASSEMBLY
BACKUP JAWS: 3-1/2″ – 10-3/4″
JAWS AVAILABLE: 3-1/2” – 9-7/8”
(Other sizes available upon request.)
Lift cylinder or spring hanger
Load cell/Torque gauge
2,150 (977 kg)
.
